Lancom 1803VA-4G

Product code: 11645822 // MPN: 62155 // EAN: 4044144621550

€1.835,90 (inc. VAT)

Available from 4 to 10 days (3 pcs available)

Add to wishlist

ROLINE GREEN UTP Patchkabel Cat.6A (Class EA). LSOH. slim. blau. 3 m

Code: 22001422

€7,30

Available from 4 to 10 days

Device Type	Wireless router - 4-port switch (integrated)
Enclosure Type	Desktop, wall-mountable
Connectivity Technology	Wired, wireless
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity	VLAN IDs: 4096 VPN tunnels: 5 VoIP local subscribers: 10 Simultaneous VoIP calls: 60 SIP provider accounts: 25
Network / Transport Protocol	L2TPv3, ARP, DHCP, IPv6, DHCPv6, LDRA, BOOTP, IPv4, Bonjour, HTTP, HTTPs, DNS, DDNS, NTP, PPPoE, RTP, TFTP, L2TPv2, IPSec, PPTP
Routing Protocol	RIP-2, BGP-4, OSPFv2, LISP, IGMP, MLD, VRRP, IGMPv3, MLDv2, RIP-1
Remote Management Protocol	RADIUS, ICMP, NTP, SNMP 1, SNMP 2c, SNMP 3, TACACS+, TFTP, Syslog
Encryption Algorithm	MPPE, 3DES-168, IKEv2, IKE, 128-bit AES-CBC, 192-bit AES-CBC, 256-bit AES-CBC, 1024-bit RSA, 2048-bit RSA, 3072-bit RSA, 4096-bit RSA, Chacha20-Poly 1305, ECDSA 256-bit, ECDSA 384-bit, ECDSA 512-bit, FIPS 140, MD5, SHA-1, SHA-256, SHA-384, SHA-512
Authentication Method	PAP, CHAP, MS-CHAP, MS-CHAP v.2, RADSEC, RADIUS, TACACS+, X.509 certificates, XAUTH authentication
Features	2x2 MIMO technology, VLAN support, IGMP snooping, MLD snooping, EoGRE, ARP lookup, LLDP support, RSTP support, STP support, ARP support, proxy ARP, LACP, QoS, ToS, DiffServ support, ACL support, DoS protection, IPS, IP spoofing, password protection, reset button, Stealth Mode, traffic shaping, URL blocker, PPP, IPv4 and IPv6 dual stack, ARF, HTTP server, HTTPS server, DNS client, DNS server, DNS relay, DNS proxy, DDNS, DHCP relay, DHCP client, DHCP server, NetBIOS/IP proxy, NTP client, SNTP server, Bonjour proxy, policy based routing, DHCPv6 client, DHCPv6 relay, DHCPv6 server, PIM, IGMP proxy, MLD proxy, Multicast routing, E-mail alert, SNMP traps, FirmSafe, load balancing, VPN redundancy, line monitoring, SCEP, certificate revocation lists (CRL), OCSP support, IPSec NAT-T, 2-factor authentication, DTMF support, SIP ALG, DPBO, auto firmware update, NetFlow, SD-LAN support, SD-WAN support, 1 fan
Compliant Standards	IEEE 802.1Q, IEEE 802.3az
Communications	Communications
Type	DSL modem
Digital Signaling Protocol	VDSL, ADSL, ADSL2, ADSL2+
Mobile Communication Protocol	LTE, UMTS, HSPA
Generation	3G, 4G
Cellular Band	LTE B1, LTE B20, LTE B28, LTE B3, LTE B32, LTE B38, LTE B40, LTE B41, LTE B42, LTE B43, LTE B7, LTE B8
Protocols & Specifications	ITU G.993.2, ITU G.993.2 Annex Q, ITU G.993.5, ITU G.992.1, ITU G.992.3, ITU G.992.5, ITU G.992.5 Annex A, ITU G.992.5 Annex B, ITU G.992.5 Annex J, ITU G.992.5 Annex M
Max Transfer Rate	300 Mbps
IP Telephony	IP Telephony
VoIP Functionality	VoIP gateway
VoIP Protocols	SIP, RTP, SRTP
Voice Codecs	T.38, G.711µ-law, G.711a-law, G.722, G.723, G.726, G.729, iLBC, Opus, ADPCM, AAC
Telephony Interfaces	2 phone (FXS), 2 line (ISDN BRI)
Expansion / Connectivity	Expansion / Connectivity
Interfaces	LAN / DMZ / WAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 2 x BRI WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45/SFP Phone line: 2 x FXS - RJ-11 USB 2.0: 1 x 4 pin USB Type A Antenna: 2 x SMA Serial: 1 x 24 pin USB-C WAN: 1 x DSL - RJ-45
Expansion Slots	1 (total) / 1 (free) x Micro-SIM
Aerial	Aerial
Aerial	External detachable
Antenna Qty	2
Gain Level	2 dBi
Power	Power
Power Device	External power adapter
Voltage Required	AC 230 V
Miscellaneous	Miscellaneous
Included Accessories	2 aerials
Cables Included	1 x network cable - 3 m 1 x modem cable - 4.25 m 2 x RJ-11 to TAE adapter
Localisation	Europe
Software / System Requirements	Software / System Requirements
OS Provided	LCOS 10.80
Dimensions & Weight	Dimensions & Weight
Width	29.3 cm
Depth	19 cm
Height	4.4 cm
Weight	760 g
Manufacturer Warranty	Manufacturer Warranty
Service & Support	Limited warranty - 3 years
Environmental Parameters	Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
Humidity Range Operating	0 - 95% (non-condensing)
