4+2P TP-LINK Omada SG3206HPP M RM POE++

Product code: 11720122 // MPN: SX3206HPP // EAN: 6935364006617

€801,80 (inc. VAT)

Available from 4 to 10 days (10 pcs available)

Add to wishlist

ARUBA 6200M 24G CL4 POE-STOCK

Code: 11744222

€4.694,50

Available from 4 to 10 days

Device Type	Switch - 6 ports - L2+ - Managed
Enclosure Type	Desktop, rack-mountable
Subtype	10 Gigabit Ethernet
Power Over Ethernet (PoE)	PoE++
PoE Budget	200 W
Performance	Switching capacity: 120 Gbps Â¦ Packet forwarding rate: 89.28 Mpps
Capacity	Priority queues: 8 Â¦ Maximum aggregation groups: 8 Â¦ Ports per aggregation group: 8 Â¦ Layer 2 multicast filtering profiles: 256 Â¦ Layer 2 multicast filtering entries per profile: 16 Â¦ VLAN groups: 4000 Â¦ Binding entries: 512 Â¦ MAC addresses per port: up to 64 Â¦ IP interfaces: 16 Â¦ Static routes: 48 Â¦ Static ARP entries: 128
MAC Address Table Size	32K entries
Jumbo Frame Support	9KB
Routing Protocol	IGMPv2, IGMP, IGMPv3, static IPv6 routing, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, ICMP, DHCP, IPv4, IPv6
Encryption Algorithm	SSL 3.0, TLS 1.2
Authentication Method	Secure Shell (SSH), TACACS+, Secure Shell v.2 (SSH2)
Features	Flow control, network monitoring, IGMP snooping, port mirroring, store and forward, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Quality of Service (QoS), DHCP server, MLD snooping, Cable Diagnostics Function, bandwidth control, DHCP relay, IP-MAC binding, Multicast VLAN Registration (MVR), port isolation, static routing, Class of Service (CoS), Strict Priority (SP), tagged VLAN, Generic VLAN Registration Protocol (GVRP), Denial of Service (DoS), 2 fans, Time-controlled ACLs support, Protocol-based VLANs support, system log, Link Aggregation, Management Information Base (MIB) II, dual image support, rate limit, Software Defined Networking (SDN), Authentication, Authorization and Accounting (AAA), Voice VLAN, Private VLAN, IGMP fast leave, VLAN group, proxy ARP, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), BPDU Filter, Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, loopback detection, queue scheduling support, schedule reboot, DSCP prioritisation, device discovery, DHCPv6 snooping, ACL MAC based
Compliant Standards	IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3an, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3bt
RAM	256 MB
Flash Memory	32 MB
Status Indicators	Power, system, link/activity, PoE max
Expansion / Connectivity	Expansion / Connectivity
Interfaces	4 x 100/1000/2.5G/5G/10GBase-T RJ-45 PoE++ - 60 W Â¦ 2 x 10GBase-X SFP+ Â¦ 1 x console RJ-45 Â¦ 1 x micro-USB Type B console
Power	Power
Power Device	Internal power supply
Voltage Required	AC 100-240 V (50/60 Hz)
Power Consumption Stand by	13.52 Watt
Miscellaneous	Miscellaneous
Included Accessories	Rubber feet
Rack Mounting Kit	Included
Compliant Standards	FCC, RoHS
Software / System Requirements	Software / System Requirements
OS Required	UNIX, Apple MacOS, Novell NetWare, Linux, Microsoft Windows 98SE/2000/NT/XP/Vista/7/8/10, Microsoft Windows 11
Dimensions & Weight	Dimensions & Weight
Width	29.4 cm
Depth	18 cm
Height	4.4 cm
Environmental Parameters	Environmental Parameters
Min Operating Temperature	0 Â°C
Max Operating Temperature	50 Â°C
Humidity Range Operating	10 - 90% RH (non-condensing)
Min Storage Temperature	-40 Â°C
Max Storage Temperature	70 Â°C
Humidity Range Storage	5 - 90% RH (non-condensing)
