SWITCHES

Management features
Switch type: Managed
Switch layer: L2
Feature: Quality of Service (QoS) support
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 24
Combo SFP ports quantity: 4
Power connector: AC-in jack
Network
Networking standards: IEEE 802.3. IEEE 802.3ab. IEEE 802.3af. IEEE 802.3at. IEEE 802.3az. IEEE 802.3u. IEEE 802.3x. IEEE 802.3z
Copper ethernet cabling technology: 10BASE-T. 100BASE-TX. 1000BASE-T
Feature: Full duplex
Feature: Half duplex
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Rate limiting
Feature: Spanning tree protocol
Ethernet LAN data rates: 10.100.1000 Mbit/s
Feature: VLAN support
Virtual LAN features: Voice VLAN
Data transmission
Switching capacity: 56 Gbit/s
Forwarding rate: 41.66 Mpps
MAC address table: 8000 entries
Feature: Jumbo frames support
Jumbo frames: 10000
Packet buffer memory: 4.1 MB
Security
DHCP features: DHCP snooping
Feature: Access Control List (ACL)
Feature: IGMP snooping
Feature: SSH/SSL support
Feature: BPDU filtering/protection
Queue scheduling algorithms: Strict Priority Queue (SPQ). Weighted Round Robin (WRR)
Multicast features
Feature: Multicast support
Protocols
Feature: GARP VLAN Registration Protocol (GVRP)
IPv4 & IPv6 features: IPv4/IPv6 access-control list (ACL)
Design
Feature: Rack mounting
Product colour: Black
Feature: Reset button
LED indicators: Alarm. LAN. PoE. Power. System
Number of fans: 2 fan(s)
Performance
Internal memory: 1024 MB
Flash memory: 16 MB
Power
Power source: AC/PoE
Feature: Power supply included
AC input voltage: 100 - 240 V
Power consumption (max): 450 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 24
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 370 W
Other features
Warranty period: 2 year(s)
Operational conditions
Operating temperature (T-T): -5 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Weight & dimensions
Width: 441 mm
Depth: 270 mm
Height: 45 mm
Weight: 5.7 kg
Packaging content
Feature: Manual
