Wirelessly transmits HDMI video and audio signals in UHD 4K/30Hz over a distance of up to 30 m with an unobstructed view

- Wireless HDMI signal transmission up to 30 m (unobstructed view)
- Point-to-point connection - 1x transmitter (source) + 1x receiver (output device)
- Supports resolutions of up to 4K UHD (2160p/30Hz)
- Easy operation and handling thanks to Plug & Play - Just plug in and get started. no driver or software required
- Power supply via USB-C connection
- AES 128 bit encryption
- WPA2 protocol
- HDMI 2.0/1.4
- HDCP 2.2/1.4

Experience wireless audio and video transmission in sharp UHD 4K/30Hz with the 4K Wireless HDMI Extender. The set is designed for easy setup without a driver or software thanks to Plug & Play. With a range of up to 30 meters with an unobstructed view. it guarantees reliable transmission. AES 128 encryption and the WPA2 protocol ensure secure data transmission. Compatible with HDMI 2.0/1.4 and HDCP 2.2/1.4. This is ideal for home theaters. conference rooms and training facilities. Discover the freedom of wireless entertainment!

Features
Type: AV transmitter & receiver
Maximum resolution: 3840 x 2160 pixels
Maximum transfer distance: 30 m
Maximum refresh rate: 30 Hz
Audio output channels: 2.0 channels
LED indicators: Status
Supported video modes: 1080p. 2160p
Supported graphics resolutions: 1920 x 1080 (HD 1080). 3840 x 2160
Audio formats supported: PCM
Security algorithms: 128-bit AES. WPA2
Video compression formats: H.265
Feature: HDCP
Material: ABS
Feature: Plug and Play
HDCP version: 2.2
Product colour: Black. Silver
Ports & interfaces
Connectivity technology: Wired & Wireless
Feature: Wi-Fi
HDMI in: 1
Number of HDMI outputs: 1
HDMI version: 2.0
Power
Power source type: USB
Operating voltage: 5 V
Power consumption (transmitter) (max): 3 W
Power consumption (receiver) (max): 4 W
Power consumption (transmitter) (max): 1000 mA
Power consumption (receiver) (max): 600 mA
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Receiver dimensions (WxDxH): 34 x 81 x 13 mm
Receiver weight: 28 g
Transmitter dimensions (WxDxH): 34 x 81 x 13 mm
Transmitter weight: 31 g
Packaging data
Quantity per pack: 2 pc(s)
Package width: 119 mm
Package depth: 119 mm
Package height: 49 mm
Package weight: 290 g
Packaging content
Cables included: USB Type-A. USB Type-C
Feature: Quick start guide
