DIGITAL SIGNAGE

Enjoy a more natural way of working
The BIG PAD L2B range of smart interactive displays combines genuine ‘4K reading and writing’ and an intuitive ‘Pen-on-Paper’ user experience with Zero Bonding and Sharp’s PrecisionTouch technology. The single USB-C connector makes it so simple to walk into a room. plug in your device and start working together straightaway. The L2B series also features an integrated Android PC with whiteboard. overlay writing mode and wireless screen sharing functionality as well as graded security to help enhance your productivity.

The BIG PAD L2B series is the perfect choice for busy office environments. boardrooms. meeting rooms and training sessions that require quick responsive operation and smart integrated collaboration tools. It encourages effective group teamwork. promotes idea sharing and helps people deliver great presentations and achieve better meeting outcomes.

Display
Display diagonal: 190.5 cm (75")
Display brightness: 350 cd/m²
Display resolution: 3840 x 2160 pixels
HD type: 4K Ultra HD
Panel type: IPS
LED backlighting type: Direct-LED
Native aspect ratio: 16:9
Contrast ratio (typical): 5000:1
Response time: 8.5 ms
Feature: Touchscreen
Touch technology: Multi-touch
Number of simultaneous touchpoints: 20
Viewing angle. horizontal: 178°
Viewing angle. vertical: 178°
Screen glass thickness: 3.4 mm
Haze rate: 8%
Hardness: 8H
Computer system
Operating system installed: Android
Operating system version: 9
Feature: Built-in processor
Processor architecture: ARM Cortex-A73
User memory: 32 GB
RAM capacity: 4 GB
Audio
Feature: Built-in speaker(s)
Number of built-in speakers: 2
Speaker power: 20 W
Network
Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Feature: Bluetooth
Bluetooth version: 5.0
Feature: Ethernet LAN
Ethernet LAN data rates: 10.100 Mbit/s
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
USB 2.0 ports quantity: 1
HDMI ports quantity: 3
USB Type-C ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
VGA (D-Sub) ports quantity: 1
Headphone connectivity: 3.5 mm
Audio output: 1
RS-232 ports: 1
Ergonomics
Product colour: Black
Certification: CE| FCC| RCM| REACH| RoHS| UL/C-UL
Power
Power consumption (max): 400 W
Power consumption (standby): 0.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
System requirements
Windows operating systems supported: Windows 10. Windows 11. Windows 8.1
Feature: Mac compatibility
Feature: Linux operating systems supported
Mobile operating systems supported: Android 9.0
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Width: 1709.4 mm
Depth: 85.7 mm
Height: 1019.8 mm
Weight: 49.5 kg
Packaging data
Package width: 1863 mm
Package depth: 225 mm
Package height: 1155 mm
Package weight: 62 kg
Packaging content
Feature: Manual
Cables included: AC. HDMI. USB
Feature: Remote control included
Feature: Batteries included
Feature: Stylus included
Number of stylus pens: 2
Feature: Open Pluggable Specification (OPS) included
