ASRock Phantom Gaming B860I Lightning WiFi , Motherboard , mini ITX , LGA1851 Socket , B860 Chipset , USB-C 3.2 Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2 , 2.5 Gigabit LAN, Bluetooth, Wi-Fi 6E , onboard graphics (CPU required) , HD Audio (8-c

Κωδικός: 16636522 // Κωδικός προμηθευτή: 90-MXBRZ0-A0UAYZ // EAN: 4711581490420

€231,10 (συμπ. ΦΠΑ)

Διαθέσιμο από 4-8 εργάσιμες ημέρες (8 τεμάχια διαθέσιμα)

Προσθήκη στη wishlist

Δείτε επίσης

Gigabyte H610M D3W (H610,S1700,mATX,DDR5

Κωδικός: 19690523

€87,20

4-10 εργάσιμες ημέρες

Product Type	Motherboard - mini ITX
Chipset Type	Intel B860
Processor Socket	LGA1851 Socket
Max Processors Qty	1
Compatible Processors	(supports Intel Core Ultra processors (Series 2))
Supported RAM	Supported RAM
Max Size	128 GB
Technology	DDR5
Bus Clock	9333 MHz (O.C.), 6800 MHz (O.C.), 6400 MHz
Supported RAM Integrity Check	Non-ECC
Registered or Buffered	Unbuffered, clocked unbuffered
Features	Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) 3.0, AMD EXPO technology
Audio	Audio
Type	HD Audio (8-channel)
Audio Codec	Realtek ALC1220
Compliant Standards	High Definition Audio
LAN	LAN
Network Controller	Dragon RTL8125BG
Network Interfaces	2.5 Gigabit Ethernet, Bluetooth 5.3, 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Expansion / Connectivity	Expansion / Connectivity
Expansion Slots	1 x CPU 2 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x M.2 socket (2230 M.2 Key E slot) 2 x M.2 socket (2280 M.2 Key M slot)
Storage Interfaces	SATA-600 -connectors: 3 x 7pin SATA - RAID 0 / RAID 1 / RAID 5 PCIe 5.0 -connectors: 1 x Blazing M.2 PCIe 4.0 -connectors: 1 x Hyper M.2
Interfaces	2 x aerial 1 x HDMI 1 x SPDIF out 1 x Thunderbolt 4 2 x USB 3.2 Gen 2 4 x USB 3.2 Gen 1 1 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x microphone - mini-jack 1 x audio line-out - mini-jack
Internal Interfaces	1 x USB-C 3.2 Gen 2 - header 2 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x audio - header
Power Connectors	24-pin main power connector, 8-pin ATX12V connector
Features	Features
BIOS Type	AMI
BIOS Features	UEFI BIOS
Hardware Features	10+1+1+1+1 Power Phase Design, Enlarged Heatsink Armor, Memory OC Shield, pre-mounted I/O shield, 20K black capacitors, BIOS FlashBack button, ASRock Auto Driver Installer, ASRock POST Status Checker (PSC), Intel Hybrid Technology, Intel Turbo Boost Max Technology 3.0, Intel Thermal Velocity Boost (TVB), Intel Adaptive Boost Technology (ABT), CUDIMM support, 10 Layer PCB, ASRock EZ Mode, ASRock Full HD UEFI, ASRock Instant Flash, ASRock My Favorites in UEFI, ASRock Polychrome RGB, Surface Mount Technology (SMT), VRM heatsink design, M.2 heatsink, Smart Power Stage (SPS) technology, aluminium heatsink design, enlarged M.2 heatsink, metal backplate, chipset heatsink, Nahimic Audio Enhacer, DIY Friendly Design, ASRock Steel Slots
Miscellaneous	Miscellaneous
Included Accessories	2 x ASRock WiFi 2.4/5/6 GHz Antennas, thermistor cable, 2 x M.2 screws
Cables Included	2 x Serial ATA cable
Software Included	ASRock Phantom Gaming LAN Software, ASRock Phantom Gaming Tuning, ASRock Polychrome SYNC
Compliant Standards	HDCP 2.3, FCC, ErP Ready, EuP Ready
Width	17 cm
Depth	17 cm
