Server HPE DL360 Gen11 1U 4514Y 64GB-R 8SFF MR408i-o 2x480GB 2x1000W

Product code: 17904322 // MPN: P77237-425 // EAN: 0190017767710

€11.494,35 (inc. VAT)

Available from 4 to 10 days (1 pcs available)

Add to wishlist

Server HPE PROLIANT DL325 GEN11 9115 3

Code: 18309022

€10.549,90

Available from 4 to 10 days

Type	Server
Product Form Factor	Rack-mountable - 1U
Embedded Security	Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability	2-way
Hot-Swap Bays Qty	8
Localisation	Region: Europe
Processor / Chipset	Processor / Chipset
CPU	Intel Xeon Silver 4514Y
Clock Speed	2 GHz
Max Turbo Speed	3.4 GHz
Number of Cores	16-core
CPU Qty	1
Max CPU Qty	2
CPU Upgradability	Upgradable
Processor Main Features	Intel Turbo Boost Technology
Chipset Type	Intel C741
Cache Memory	Cache Memory
Installed Size	L3 Cache - 30 MB
Cache Per Processor	30 MB
RAM	RAM
Installed Size	64 GB (installed) / 8 TB (max)
Technology	DDR5 SDRAM - Advanced ECC
Effective Memory Speed	2800 MHz
Rated Memory Speed	2800 MHz
Form Factor	DIMM 288-pin
Slots	32 (Total) / 30 (empty)
Features	HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only
Configuration Features	2 x 32 GB
Hard Drive	Hard Drive
Type	SSD
Capacity	2 x 480 GB
Interface Type	SATA
Storage Controller	Storage Controller
Type	1 x RAID - OCP
Controller Interface Type	Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name	HPE MR408i-o Gen11 SPDM
Channel Qty	8
RAID Level	RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60
Buffer Size	4 GB
Optical Storage	Optical Storage
Type	No optical drive
Monitor	Monitor
Monitor Type	None.
Graphics Controller	Graphics Controller
Video Memory	16 MB
Video Interfaces	VGA
Networking	Networking
Ethernet Ports	2 x 10 Gigabit Ethernet
Ethernet Controller	Broadcom BCM57416
Data Link Protocol	10 Gigabit Ethernet
Remote Management Protocol	SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller	Integrated Lights-Out 6
Features	Wake on LAN (WoL), PXE support
Expansion / Connectivity	Expansion / Connectivity
Bays	1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots	2 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces	1 x HPE iLO - Type A (1 in front) 1 x HPE iLO - RJ-45 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal) 1 x VGA 2 x LAN (10Gigabit Ethernet) 1 x USB 2.0
Miscellaneous	Miscellaneous
Included Accessories	5 x standard fans
Compliant Standards	ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4
Power	Power
Device Type	Power supply - hot-plug
Power Redundancy	Optional
Power Redundancy Scheme	1+1 (with optional power supply)
Installed Qty	2
Max Supported Qty	2
Voltage Required	AC 100-240 V
Power Provided	1000 Watt
80 PLUS Certification	80 PLUS Titanium
Operating System / Software	Operating System / Software
OS Provided	No operating system
OS Certified	VMware vSphere 8.0 (ESXi), SuSE Linux Enterprise Server 11 SP4, Ubuntu 22.04
Software	HPE Server UEFI
Sustainability Information	Sustainability Information
ENERGY STAR Certified	Yes
ENERGY STAR Version	4.0
Manufacturer Warranty	Manufacturer Warranty
Service & Support	Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight	Dimensions & Weight
Width	43.46 cm
Depth	75.31 cm
Height	4.29 cm
Weight	14.56 kg
Environmental Parameters	Environmental Parameters
Min Operating Temperature	10 °C
Max Operating Temperature	35 °C
Humidity Range Operating	8 - 90% RH (non-condensing)
