| Product Type |
Motherboard - micro ATX |
| Chipset Type |
AMD A620 |
| Processor Socket |
Socket AM5 |
| Max Processors Qty |
1 |
| Compatible Processors |
Ryzen (supports Ryzen 7000 Series) |
| Supported RAM |
Supported RAM |
| Max Size |
96 GB |
| Technology |
DDR5 |
| Bus Clock |
4400 MHz, 4800 MHz, 5200 MHz, 5600 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.) |
| Supported RAM Integrity Check |
Non-ECC |
| Registered or Buffered |
Unbuffered |
| Features |
Dual channel memory architecture, AMD EXPO technology, Intel Extreme Memory Profiles (XMP) |
| Audio |
Audio |
| Type |
HD Audio (8-channel) |
| Compliant Standards |
High Definition Audio |
| LAN |
LAN |
| Network Interfaces |
Gigabit Ethernet |
| Expansion / Connectivity |
Expansion / Connectivity |
| Expansion Slots |
1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 3.0 x1 1 x M.2 socket (2580 M.2 Key M slot) |
| Storage Interfaces |
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 |
| Interfaces |
1 x DisplayPort 1 x HDMI 2 x USB 3.2 Gen 1 4 x USB 2.0 1 x LAN (Gigabit Ethernet) 1 x PS/2 keyboard / mouse 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack |
| Internal Interfaces |
2 x USB 3.2 Gen 1 - header 4 x USB 2.0 - header 1 x audio - header 1 x SPI - header |
| Power Connectors |
24-pin main power connector, 8-pin ATX12V connector |
| Features |
Features |
| BIOS Type |
AMI |
| BIOS Features |
UEFI BIOS, ACPI 5.0 support, DMI 2.7 support, PnP 1.0a support, SMBIOS 2.7 support, WfM 2.0 support |
| Hardware Features |
Q-Flash, Q-Flash Plus, 5+2+2 Phase Power Design, GIGABYTE Smart Fan 6, Solid Pin Power Connectors, DIY Friendly Design |
| Miscellaneous |
Miscellaneous |
| Software Included |
Norton Internet Security |
| Width |
22.5 cm |
| Depth |
23 cm |
