| Product Type |
Motherboard - ATX |
| Chipset Type |
Intel C266 |
| Processor Socket |
LGA1700 Socket |
| Max Processors Qty |
1 |
| Compatible Processors |
Xeon E, Pentium |
| Supported RAM |
Supported RAM |
| Max Size |
128 GB |
| Technology |
DDR5 |
| Bus Clock |
4400 MHz |
| Supported RAM Integrity Check |
ECC |
| Registered or Buffered |
Unbuffered |
| Features |
Dual channel memory architecture |
| Graphics |
Graphics |
| Graphics Controller |
ASPEED AST2600 |
| Dedicated Video Memory |
64 MB |
| LAN |
LAN |
| Network Controller |
Intel X710-AT2 |
| Network Interfaces |
10 Gigabit Ethernet |
| Expansion / Connectivity |
Expansion / Connectivity |
| Expansion Slots |
1 x CPU 4 x DIMM 288-pin 2 x PCIe 4.0 x8 1 x PCIe 5.0 x8 1 x PCIe 5.0 x16 2 x M.2 socket (22110 M.2 Key M slot) |
| Storage Interfaces |
SATA-600 -connectors: 8 x 7pin Serial ATA PCIe -connectors: 2 x M.2 |
| Interfaces |
1 x VGA 4 x USB 3.2 Gen 2 2 x USB 2.0 2 x LAN (10Gigabit Ethernet) 1 x management |
| Internal Interfaces |
1 x SPI - header 1 x serial - header 1 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB 3.2 Gen 2 - Type A 1 x VGA - header |
| Power Connectors |
24-pin main power connector, 8-pin ATX12V connector |
| Features |
Features |
| Hardware Monitoring |
CPU core temperature, fan control |
| Hardware Features |
ASMB11-iKVM |
| Miscellaneous |
Miscellaneous |
| Included Accessories |
IO shield |
| Width |
30.5 cm |
| Depth |
24.4 cm |
| Weight |
760 g |
| Dimensions & Weight (Shipping) |
Dimensions & Weight (Shipping) |
| Shipping Weight |
1.3 kg |
