DIGITAL SIGNAGE

When imaging precision cannot be compromised

When imaging precision and 24/7 operational reliability cannot be compromised, the 5th generation of NEC MultiSync P series presents best-in-class performance with an advanced feature set for mission-critical applications

Unparalleled clarity of detail and colour accuracy is achieved with 8K signal processing, wide colour gamut and the integrated NEC SpectraView engine controlling all visual parameters. Even in bright ambient light conditions, high brightness levels of 700 cd/m² combined with a high haze filter guarantees exceptional readability with no annoying reflections. Despite its slim, elegant profile, the quality build is robust for use in public spaces, with an all-metal chassis for fire-retardancy. Featuring NEC Open Modular Intelligence (OMI) slot-in technology, choose scalable computing power with Raspberry Pi Compute Module 4 or the more powerful Intel Smart Display Modules (IntelSDM) for tailor-made signage solutions.

For best visualisation in control rooms and production lines, for passenger information and wayfinding signage; the NEC P Series is trusted for safety and long-life, fit-for-purpose performance.

Display
Panel type: IPS
LED backlight: Yes
LED backlighting type: Edge-LED
Display diagonal: 124.5 cm (49")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 700 cd/m²
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Response time: 8 ms
Contrast ratio (typical): 8000:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.073 billion colours
Display diagonal (metric): 124.5 cm
Horizontal scan range: 15 - 135 kHz
Vertical scan range: 23 - 76 Hz
Native refresh rate: 60 Hz
Haze rate: 28%
Ports & interfaces
HDMI ports quantity: 3
HDMI input ports quantity: 2
HDMI output ports quantity: 1
DisplayPorts quantity: 3
DisplayPorts in: 2
DisplayPorts out: 1
USB port: Yes
USB ports quantity: 3
USB version: 2.0
Ethernet LAN (RJ-45) ports: 2
Audio (L/R) out: 1
RS-232 interface: Yes
Design
Product design: Digital signage flat panel
Placement supported: Indoor
Orientation: Horizontal/Vertical
Product colour: Black
VESA mounting: Yes
Panel mounting interface: 300 x 300 mm
Bezel width (bottom): 1.25 cm
Bezel width (side): 1.2 cm
Bezel width (top): 1.2 cm
Performance
Purpose: Universal
Picture-in-Picture: Yes
Firmware upgradeable: Yes
Operating hours (hours/days): 24/7
HDCP: Yes
Power
Power consumption (typical): 105 W
Power consumption (standby): 2 W
Energy efficiency class (SDR): G
Energy efficiency class (HDR): G
Energy consumption (SDR) per 1000 hours: 106 kWh
Energy consumption (HDR) per 1000 hours: 98 kWh
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Weight & dimensions
Display width: 1103.4 mm
Display depth: 61.1 mm
Display height: 636.2 mm
Display weight: 22.9 kg
Packaging data
Package width: 1298 mm
Package depth: 224 mm
Package height: 860 mm
Package weight: 29.8 kg
Packaging content
Remote control included: Yes
Batteries included: Yes
Cables included: AC, HDMI
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 10 - 90%
Logistics data
Harmonized System (HS) code: 85285210
Sensors
Ambient light sensor: Yes
Network
Ethernet LAN: Yes
Ethernet LAN data rates: 100 Mbit/s
