AM5 ASUS ROG STRIX B850-E Gaming WIFI

Product code: 11171122 // MPN: 90MB1J60-M0EAY0 // EAN: 4711387769300

€474,30 (inc. VAT)

Available from 4 to 10 days (9 pcs available)

Add to wishlist

ASUS ROG STRIX B850-A GAMING WIFI7 NEO (AMD,AM5,DDR5,ATX)

Code: 20757023

€429,55

8-12 business days

Product Type	Motherboard - ATX
Chipset Type	AMD B850
Processor Socket	Socket AM5
Max Processors Qty	1
Compatible Processors	Ryzen (supports Ryzen 7000/8000/9000 Series)
Supported RAM	Supported RAM
Max Size	192 GB
Technology	DDR5
Bus Clock	4000 MHz (O.C.)
Supported RAM Integrity Check	Non-ECC, on-die ECC
Registered or Buffered	Unbuffered
Features	AMD EXPO technology, dual channel memory architecture
Audio	Audio
Type	HD Audio (8-channel)
Audio Codec	Realtek ALC4080
Compliant Standards	High Definition Audio, DTS Sound Unbound
LAN	LAN
Network Controller	Intel I225-V
Network Interfaces	2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4
Expansion / Connectivity	Expansion / Connectivity
Expansion Slots	1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 4.0 x16 (x4 mode) 1 x M.2 socket (2242/2280/22110 M.2 Key M slot) 1 x M.2 socket (2242/2260/2280 M.2 Key M slot) 3 x M.2 socket (2280 M.2 Key M slot)
Storage Interfaces	SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 PCIe 5.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10 PCIe 4.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 / RAID 10
Interfaces	1 x HDMI 1 x DisplayPort 1 x USB-C 3.2 Gen2x2 1 x USB4 6 x USB 3.2 Gen 2 4 x USB 2.0 1 x LAN (2.5Gigabit Ethernet) 1 x SPDIF out 1 x microphone - mini-jack 1 x audio line-out - mini-jack 2 x aerial
Internal Interfaces	4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB-C 3.2 Gen 2 - header 1 x audio - header
Power Connectors	24-pin main power connector, 4-pin ATX12V connector, 2 x 8-pin ATX12V connectors
Features	Features
BIOS Type	AMI
BIOS Features	UEFI BIOS, ASUS EZ Flash 3
Sleep / Wake Up	Wake on LAN (WOL), wake on PME
Hardware Features	ASUS OptiMem II, SupremeFX Shielding technology, Savitech SV3H712 amplifier, BIOS FlashBack button, Water Pump Header, jack retasking, audio jack detect technology, ASUS Extreme Engine Digi+, 5K Black Metallic Capacitors, ASUS Q-Design, M.2 Q-Latch, PCIe Slot Q-Release, Q-LED, Q-DIMM, Q-Slot, M.2 heatsink, VRM heatsink design, ASUS EZ DIY, BIOS FlashBack LED, ASUS ProCool, pre-mounted I/O shield, ASUS SafeSlot, ASUS SafeDIMM, ASUS Aura Sync, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, CrashFree BIOS 3, 16+2+2 Phase Power Design, 80A Power Stage, DIY Friendly Design, ASUS Enhanced Memory Profile (AEMP), Q-Code
Miscellaneous	Miscellaneous
Included Accessories	Thermal pad for M.2 SSD, ASUS Wi-Fi Q-antenna, cable ties, ROG key chain, STRIX stickers, ROG thank you card, 5 x M.2 rubber package
Cables Included	2 x Serial ATA cable
Software Included	ROG GameFirst VI, ROG CPU-Z, Sonic Radar III, Sonic Studio III, Armoury Crate, AIDA64 Extreme (60 days trial), ASUS AURA Creator, ASUS AI Suite III, ASUS Turbo App, PC Cleaner, MyAsus, WinRAR, ASUS DriverHub, HWiNFO, WinRAR (40 days trial), Norton 360 for Gamers (60 days trial), Adobe Creative Cloud (free trial), ASUS Fan Xpert 4
Compliant Standards	FCC Part 15 Class B, VCCI Class B ITE, JATE, EU REACH, EU RoHS, UKCA, DisplayPort 1.4
Width	30.5 cm
Depth	24.4 cm
