SWITCHES

Stylish Outlook
New ID design with carbon fiber look name plate delivers the modern look-and-feel in the closet.
Choose a right L3 switch for your network

High Availability
The XGS4600 Series comes with Gigabit connectivity and four integrated 10-Gigabit SFP+ slots that enable high-speed uplink connections for affordable. reliable network elements.

Stacking Capability
The XGS4600-32/32F allows creating a physical stack through one or two 10-Gigabit SFP+ slots. XGS4600 series features dynamic routing to simplify cross-subnet communications for businesses such as hospitality venues and education institutions that operate complex networks.

High Resiliency
The XGS4600 Series is designed to support active-standby power redundancy to trigger backup power supply to take over in case the main power supply fails.

Management features
Switch type: Managed
Switch layer: L3
Feature: Web-based management
Ports & interfaces
SFP module slots quantity: 48
SFP+ module slots quantity: 4
Network
Feature: 10G support
Feature: IP routing
Data transmission
Switching capacity: 176 Gbit/s
MAC address table: 32000 entries
Packet buffer memory: 4 MB
Security
DHCP features: DHCP server
Feature: Access Control List (ACL)
Security algorithms: SSH. SSL/TLS
Feature: MAC address filtering
Feature: SSH/SSL support
Feature: BPDU filtering/protection
Design
Feature: Rack mounting
Product colour: Black
Feature: LED indicators
Performance
Internal memory: 1024 MB
Flash memory: 64 MB
Noise level: 42.6 dB
Mean time between failures (MTBF): 815860 h
Power
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max): 70.16 W
Operational conditions
Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 95%
Storage relative humidity (H-H): 10 - 95%
Heat dissipation: 252.68 BTU/h
Weight & dimensions
Width: 441 mm
Depth: 360 mm
Height: 44 mm
Weight: 4.97 kg
Packaging data
Package width: 616 mm
Package depth: 355 mm
Package height: 107 mm
Package weight: 6.6 kg
Logistics data
Harmonized System (HS) code: 85176990
