FTE MSP17/12 Multiswitch 17/12
Product code: 17956520 // MPN: MSP17/12
€155,05 (inc. VAT)
Available from 1 to 3 days
Similar products
Multiswitches MEP have been designed to distribute sixteen complete satellite polarities (analog and digital) to a maximum of 16 users. They have a mix input for terrestrial channels passive type.
- Nr of SAT Inputs (950-2200 MHz) 16
- Nº of Terr. Inputs (5-862 MHz) 1
- Nº of Outputs (5-2200 Mhz) 12
- SAT pass attenuation (dB) 4 (typ)
- Pass AttenuationTerr. (dB) 20 (typ)
- Regulation margin SAT (dB) 12
- Commutation type DiSEqC 2.0
- Decoupling between SAT inputs (dB) > 25
- Maximum level SAT input (dBuV) 95
- Maximum level Terr. input (dBuV) 110
- LNB power supply 18 VDC Max 1000 mA
- Power supply SMPS 230 VAC / 50 Hz
- Connectors F
- Weight (grs.) 2400
- Packing quantity 1
- Preamplifiers power supply 18 VDC 100 mA
