Cisco CATALYST 9300L 48P 12MGIG

Product code: 19953522 // MPN: C9300L-48UXG-4X-A // EAN: 0889728174121

New entry

€15.598,85 (inc. VAT)

Available from 4 to 10 days (38 pcs available)

Add to wishlist

DIGITUS Switch 8-Port Gigabit 180W PoE Unmanaged black

Code: 13142422

€291,90

Available from 4 to 10 days

Device Type	Switch - 48 ports - L3 - Managed - stackable
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 (UPOE) + 4 x 10 Gigabit SFP+ (uplink)
Power Over Ethernet (PoE)	UPOE
PoE Budget	675 W
Performance	Switching capacity: 392 Gbps Â¦ Switching capacity with stacking: 712 Gbps Â¦ Forwarding rate: 291.66 Mpps Â¦ Forwarding rate with stacking: 529.76 Mpps
Capacity	IPv4 routes: 32000 Â¦ IPv6 routes: 16000 Â¦ Multicast scale: 8000 Â¦ QoS scale entries: 5120 Â¦ ACL scale entries: 5120 Â¦ VLANs supported: 4094 Â¦ Switched virtual interfaces (SVIs): 1000
MAC Address Table Size	32000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG
Encryption Algorithm	128-bit AES, 256-bit AES
Features	Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, 16MB packet buffer, DiffServ Code Point (DSCP) support, MACsec support, Control plane protection (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), secure boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, Committed Information Rate (CIR), Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0, Cisco StackWise-320 technology
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6
RAM	8 GB
Flash Memory	16 GB
Status Indicators	Status
Expansion / Connectivity	Expansion / Connectivity
Interfaces	36 x 1000Base-T RJ-45 60 W Â¦ 4 x 10GBase-X SFP+ uplink Â¦ 1 x network stack device Â¦ 1 x management (LAN) RJ-45 Â¦ 1 x console Â¦ 1 x USB 2.0 Â¦ 12 x 1/2.5/5/10GBase-T RJ-45
Power	Power
Power Device	Internal power supply - hot-plug
Installed Qty	1
Max Supported Qty	2
Power Redundancy	Optional
Power Provided	1100 Watt
Voltage Required	AC 120/230 V (50 - 60 Hz)
Miscellaneous	Miscellaneous
MTBF	273,820 hours
Compliant Standards	CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35
Dimensions & Weight	Dimensions & Weight
Width	44.5 cm
Depth	4.4 cm
Height	48.8 cm
Weight	7.65 kg
Manufacturer Warranty	Manufacturer Warranty
Service & Support	Limited warranty - replacement - lifetime - response time: next business day Â¦ Technical support - consulting - 90 days
Environmental Parameters	Environmental Parameters
Min Operating Temperature	-5 Â°C
Max Operating Temperature	45 Â°C
Humidity Range Operating	5 - 90% (non-condensing)
Min Storage Temperature	-40 Â°C
Max Storage Temperature	70 Â°C
Humidity Range Storage	5 - 90% (non-condensing)
