| Product Type |
Motherboard - micro ATX |
| Chipset Type |
AMD A620A |
| Processor Socket |
Socket AM5 |
| Max Processors Qty |
1 |
| Compatible Processors |
Ryzen (supports Ryzen 7000/8000/9000 Series) |
| Supported RAM |
Supported RAM |
| Max Size |
128 GB |
| Technology |
DDR5 |
| Bus Clock |
7200 MT/s (O.C.), 7600 MT/s (O.C.) |
| Supported RAM Integrity Check |
Non-ECC, on-die ECC |
| Registered or Buffered |
Unbuffered |
| Features |
Dual channel memory architecture, AMD EXPO technology |
| Audio |
Audio |
| Type |
HD Audio (8-channel) |
| Compliant Standards |
High Definition Audio |
| LAN |
LAN |
| Network Interfaces |
Gigabit Ethernet |
| Expansion / Connectivity |
Expansion / Connectivity |
| Expansion Slots |
1 x CPU 2 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 3.0 x1 1 x M.2 socket (2242/2260/2280 M.2 Key M slot) |
| Storage Interfaces |
PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5 SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| RAID Features |
AMD RAID Xpert2 Technology |
| Interfaces |
1 x HDMI 1 x DisplayPort 4 x USB 3.2 Gen 1 2 x USB 2.0 1 x LAN (Gigabit Ethernet) 1 x audio line-out/headphones - mini-jack 1 x microphone - mini-jack 1 x audio line-in - mini-jack 1 x PS/2 keyboard / mouse |
| Internal Interfaces |
1 x USB 3.2 Gen 1 - header 1 x USB 2.0 - header 1 x SPDIF out - header 1 x SPI - header 1 x audio - header 1 x serial - header |
| Power Connectors |
24-pin main power connector, 8-pin ATX12V connector |
| Features |
Features |
| BIOS Type |
AMI |
| BIOS Features |
UEFI BIOS, ASUS EZ Flash 3 |
| Sleep / Wake Up |
Wake on PME |
| Hardware Features |
Preboot eXecution Environment (PXE), ASUS 5X Protection III, ASUS DIGI+ VRM, LANGuard, overvoltage protection, ASUS SafeSlot Core, ASUS Stainless Steel Back I/O, ASUS Q-Design, Q-DIMM, Q-LED Core, Q-Slot, aluminium heatsink design, ASUS Aura Sync |
| Miscellaneous |
Miscellaneous |
| Included Accessories |
IO shield, M.2 screw package |
| Cables Included |
2 x Serial ATA cable |
| Software Included |
Armoury Crate, WinRAR, Norton 360 Deluxe (60 days trial), ASUS CPU-Z, PC Cleaner, ASUS TurboV EVO Utility, ASUS AURA Creator, ASUS Fan Xpert |
| Width |
22.6 cm |
| Depth |
22.1 cm |
